FPT S30 230 E Marine Engine

The S30 230 E is an in-line four-cylinder marine engine with a total displacement of 3.0 L. It produces a maximum power of 169 kW at a max. power speed of 4000 rpm, with a fuel consumption of 259 g/kW·h. The engine features high power density and premium power output to fit various application demands, while optimized structural design lowers noise and vibration greatly to guarantee superior comfort onboard.
It adopts mature FPT Industrial long blocks that have been mass-installed on hundreds of thousands of on-road and off-road machinery globally, well-known for excellent reliability and high uptime and approved by massive customers worldwide. Supported by proactive maintenance assistance and intelligent connected monitoring solutions, it effectively cuts the total cost of ownership and elevates overall operational efficiency, acting as an ideal lightweight marine power unit.

Advantages of Marine Engine S30 230 E

Clean Operation & Fuel Flexibility: Our solutions feature low emissions and full compatibility with renewable drop-in fuels, including HVO (Hydrotreated Vegetable Oil) and XTL fuels, delivering over 90% CO₂ reduction without compromising performance or service life.
Flexibility: Compact design with a low volume-to-power ratio. Full range of optional accessories available. Compliant with a wide spectrum of emission standards and classification society approvals. Available in heat exchanger cooled and keel cooled configurations.
IMO Tier II Compliance： The aftertreatment system, co-developed with Frydenbø Industri A/S, enables ultra-clean operation in compliance with the most stringent international emission regulations.

Technical Specifications

Engine Model :	S30 230 E
Arrangement :	4 Cyl. in line
Total Displacement :	3.0 L
Maximum Power :	169 kW (230 hp)
Max. Power Speed :	4000 rpm
Fuel Consumption :	259 g/kW·h
Valves per Cylinder :	4
Dimensions (L×W×H) :	780 × 776 × 755 mm
Dry Weight :	330 kg

coming soon…

Engine Model	Maximum Power	Max. Power Speed	Fuel Consumption
S30 230 E	169 kW	4000 rpm	259 g/kW·h
——END——

General Information of FPT S30 230 E Marine Engine
Engine Model	S30 230 E	Arrangement	4 Cyl. in line
Total Displacement	3.0 L	Rating	A1
Maximum Power	169 kW (230 hp)	Max. Power Speed	4000 rpm
Fuel Consumption	259 g/kW·h	Thermodynamic Cycle	Diesel 4 stroke
Air Handling	Turbocharged with aftercooler	Valves per Cylinder	4
Cooling System	Liquid	Direction of Rotation (viewed facing flywheel)	Counterclockwise
Engine Management	Electronic	Injection System	Common Rail
Emission	● IMO II ● RCD II	Dimensions¹ (L²×W×H) ¹ Dimensions can be changed according to engine options ² Length at flywheel	780 × 776 × 755 mm
Dry Weight	330 kg
——END——

Variable Speed Rating Class
Rating	Type	Definition
A1	Short range fast pleasure service	Limited operation: 10% of total running time Cruising speed: Engine speed < 90% of calibrated rated speed Maximum annual operating hours: 300 h/y
A2/B1	Long range pleasure/commercial service	Limited operation: 10% of total running time Cruising speed: Engine speed < 90% of calibrated rated speed Maximum annual operating hours: 1000 h/y
B	Light duty	Limited operation: 10% of total running time Cruising speed: Engine speed < 90% of calibrated rated speed Maximum annual operating hours: 1500 h/y
C	Medium duty	Limited operation: 10% of total running time Cruising speed: Engine speed < 90% of calibrated rated speed Maximum annual operating hours: 3000 h/y
D	Heavy duty	Continuous operation: up to 100% of total running time Maximum annual operating hours: unlimited h/y
