FPT C16 1000-III Marine Engine

The C16 1000-III is an in-line six-cylinder marine engine with a total displacement of 15.9 L. It delivers a maximum power of 662 kW at 2300 rpm, with a fuel consumption of 231 g/kW·h. It achieves superior fuel efficiency compared with competing products and supports a wide range of accessories and optional equipment to satisfy diverse marine application requirements.
Both the base engine and marine kits are manufactured by FPT Industrial. The engine offers extended service intervals of up to 600 hours, effectively cutting maintenance expenses and overall operational costs. Balancing strong power output, excellent fuel economy and convenient aftermarket support, it serves as a reliable, cost-effective marine power solution for various vessels.
Committed to providing reliable premium propulsion system and power system for all kinds of ships around the world, SeaMac is a sub-brand of EMAC group that focused on maritime application.
From engine to gearbox, from shaft to propeller, from main generator set to emergency generator set, SeaMac always provides professional and cost effective solutions for all customers.

Advantages of Marine Engine C16 1000-III

Performance: Top-tier performance with outstanding peak power and rapid torque response.The CURSOR 9 delivers best-in-class peak power. CURSOR 16 holds the Guinness World Record for the fastest diesel-powered watercraft at 277.5 km/h.
Emissions Standards: Full type approvals available. Compatible with XTL / HVO fuels (EN 15940).
Efficiency： CURSOR 9 features best-in-class fuel economy.Lower fuel consumption versus direct competitors.
Lightness and Compactness: CURSOR 9: the lightest in its class. CURSOR 16: compactness and weight of a 13L engine combined with the robustness of a 16L unit.

Technical Specifications

Engine Model :	C16 1000-III
Arrangement :	6 Cyl. in line
Total Displacement :	15.9 L
Maximum Power :	662 kW (900 hp)
Max. Power Speed :	2300 rpm
Fuel Consumption :	231 g/kW·h
Valves per Cylinder :	4
Dimensions (L×W×H) :	1470 × 1166 × 1169 mm
Dry Weight :	1640 kg

coming soon…

Engine Model	Maximum Power	Max. Power Speed	Fuel Consumption
C90 620 E-I	456 kW	2530 rpm	228 g/kW·h
C90 620 E-II	426 kW	2530 rpm	225 g/kW·h
C90 620 E-III	404 kW	2530 rpm	224 g/kW·h
C90 650 E-I	478 kW	2530 rpm	227 g/kW·h
C90 650 E-II	445 kW	2530 rpm	232 g/kW·h
C90 650 EVO-I	478 kW	2530 rpm	227 g/kW·h
C90 650 EVO-II	460 kW	2530 rpm	229 g/kW·h
C16 1000-I	735 kW	2300 rpm	228 g/kW·h
C16 1000-II	691 kW	2450 rpm	234 g/kW·h
C16 1000-III	662 kW	2300 rpm	231 g/kW·h
——END——

General Information of FPT C16 1000-III Marine Engine
Engine Model	C16 1000-III	Arrangement	6 Cyl. in line
Total Displacement	15.9 L	Rating	B
Maximum Power	662 kW (900 hp)	Max. Power Speed	2300 rpm
Fuel Consumption	231 g/kW·h	Thermodynamic Cycle	Diesel 4 stroke
Air Handling	Turbocharged with aftercooler	Valves per Cylinder	4
Cooling System	Liquid	Direction of Rotation (viewed facing flywheel)	Counterclockwise
Engine Management	Electronic	Injection System	Common Rail
Emission	● IMO II ● RCD II ● EPA Tier 3 Recreational ● China GB II (GB15097-2016)	Dimensions¹ (L²×W×H) ¹ Dimensions can be changed according to engine options ² Length at flywheel	1470 × 1166 × 1169 mm
Dry Weight	1640 kg
——END——

Variable Speed Rating Class
Rating	Type	Definition
A1	Short range fast pleasure service	Limited operation: 10% of total running time Cruising speed: Engine speed < 90% of calibrated rated speed Maximum annual operating hours: 300 h/y
A2/B1	Long range pleasure/commercial service	Limited operation: 10% of total running time Cruising speed: Engine speed < 90% of calibrated rated speed Maximum annual operating hours: 1000 h/y
B	Light duty	Limited operation: 10% of total running time Cruising speed: Engine speed < 90% of calibrated rated speed Maximum annual operating hours: 1500 h/y
C	Medium duty	Limited operation: 10% of total running time Cruising speed: Engine speed < 90% of calibrated rated speed Maximum annual operating hours: 3000 h/y
D	Heavy duty	Continuous operation: up to 100% of total running time Maximum annual operating hours: unlimited h/y
