ZICHAI L6230AZLC Series Marine Engine

The Zichai L6230AZLC series marine diesel engines are developed based on decades of experience in marine propulsion R&D and manufacturing. Featuring a robust power core, these highly reliable products offer a power range of 1213 kW to 1470 kW and a speed range of 1000 rpm. Specifically engineered for the demanding maritime operating environment, these engines ensure stable performance under prolonged heavy-load conditions. They fully comply with the International Maritime Organization’s Tier II emission standards. Achieving outstanding fuel efficiency across all operating conditions, they significantly reduce vessel operating costs. Simple routine maintenance effectively minimizes downtime, enhancing vessel availability.

coming soon…

coming soon…

coming soon…

General Specifications of L6230AZLC Series

Type:In-line, four-stroke, direct-injection, turbocharged, intercooled, irreversible
Cylinders:6
Cylinder Bore:
225 mm
Piston Stroke:
300 mm
Total Displacement :71.57 L
Rated Power:1213-1470 kW
Rated Speed:1000 rpm
Dimensions (L×W×H):3315×1145×2452 (Reference only)
Weight:<10000 kg



L6230AZLC-11470 kWL6230AZLC-1
L6230AZLC-21324 kWL6230AZLC-2
L6230AZLC-31213 kWL6230AZLC-3

Engine Model

Rated Power/kW

03006009001200150018002100
Zichai L6230AZLC Series Catalogue

Engine Model

Rated Power

Rated Speed

Engine Model

Rated Power

Rated Speed

L6230AZLC-11470 kW1000 rpmL6230AZLC-21324 kW1000 rpm
L6230AZLC-31213 kW1000 rpm
——END——

Zichai L6230AZLC Series Marine Engine

This is the list of all series of Zichai L6230AZLC Series Marine Engine.
