HND TBD620/CHD620CR DEUTZ-MWM Marine Main Engine

TBD620/CHD620CR DEUTZ-MWM Series marine main engine represents a propulsion power solution developed by HND based on a mature (DEUTZ) technology platform. It has gained widespread market recognition for its outstanding power performance, exceptional fuel economy, and superior operational reliability. This series is suitable for various types of government vessels, merchant ships, and engineering vessels, capable of meeting propulsion demands across different navigation zones. Equipped with advanced emission control technology, it easily complies with international environmental standards, providing ships with efficient and clean core power assurance.
The product combines robust power, outstanding fuel efficiency, and extended service life. It not only delivers exceptional acceleration performance but also significantly reduces operating costs. Its outstanding structural reliability and full compliance with international environmental standards ensure efficient, economical, and compliant operation of vessels under all navigational conditions.

coming soon…

coming soon…

coming soon…

General Specifications of TBD620/CHD620CR DEUTZ-MWM Series

Bore/Stroke :170/195 mm
Cylinder Arrangement :V type, Angle 90
Cylinder Numbers :
L6、V8、V12、V16
Displacement :
26.55 L、35.41 L、53.11 L、70.82 L
Compression Ratio :13.5 : 1
Min.No Load Steady Speed(Idle Speed) :600~750 r/min
Ignition Speed(20℃) :150 r/min
Rotation Direction :Anti-clockwise rotation(from flywheel end)
Lube Oil Consumption :≤1.3 g/kW·h



CHD620L6650-690 kWCHD620L6
CHD620L6CR650-690 kWCHD620L6CR
TBD620V8829-1016 kWTBD620V8
CHD620V8CR829-1016 kWCHD620V8CR
TBD620V121243-1524 kWTBD620V12
CHD620V12CR1243-1524 kWCHD620V12CR
TBD620V161658-2032 kWTBD620V16
CHD620V16CR1658-2032 kWCHD620V16CR

Engine Model

Rated Power/kW

600850110013501600185021002350
HND TBD620/CHD620CR DEUTZ-MWM Series Catalogue

Engine Model

Rated power

Fuel consumption

Engine Model

Rated power

Speed r/min

CHD620L6650-690 kW200-205 g/kW·hCHD620L6CR650-690 kW200-205 g/kW·h
TBD620V8829-1016 kW198-200 g/kW·hCHD620V8CR829-1016 kW198-210 g/kW·h
TBD620V121243-1524 kW197-200 g/kW·hCHD620V12CR1243-1524 kW197-210 g/kW·h
TBD620V161658-2032 kW198-200 g/kW·hCHD620V16CR1658-2032 kW198-210 g/kW·h
——END——

HND TBD620/CHD620CR DEUTZ-MWM Series Marine Main Engine

This is the list of all series of HND TBD620/CHD620CR DEUTZ-MWM Series Marine Main Engine.
