HND TBD234/CHD234CR DEUTZ-MWM Marine Main Engine
TBD234/CHD234CR DEUTZ-MWM Series marine main engine represents a propulsion power solution developed by HND based on a mature (DEUTZ) technology platform. It has gained widespread market recognition for its outstanding power performance, exceptional fuel economy, and superior operational reliability. This series is suitable for various types of government vessels, merchant ships, and engineering vessels, capable of meeting propulsion demands across different navigation zones. Equipped with advanced emission control technology, it easily complies with international environmental standards, providing ships with efficient and clean core power assurance.The product combines robust power, outstanding fuel efficiency, and extended service life. It not only delivers exceptional acceleration performance but also significantly reduces operating costs. Its outstanding structural reliability and full compliance with international environmental standards ensure efficient, economical, and compliant operation of vessels under all navigational conditions.
General Specifications of TBD234/CHD234CR DEUTZ-MWM Series
| Bore/Stroke : | 128/140 mm |
| Cylinder Arrangement : | V type, Angle 60 |
| Cylinder Numbers : |
6/8/12 |
| Unit Cylinder Displacement : |
1.8 L |
| Compression Ratio : | 15 : 1 |
| Min.No Load Steady Speed(Idle Speed) : | 600~750 r/min |
| Ignition Speed(20℃) : | 115 r/min |
| Rotation Direction : | Anti-clockwise rotation(from flywheel end) |
| Lube Oil Consumption : | ≤1.3 g/kW·h |
| 186-242 kW | TBD234V6 | |||||||
| 186-242 kW | CHD234V6CR | |||||||
| 249-323 kW | TBD234V8 | |||||||
| 252-323 kW | CHD234V8CR | |||||||
| 373-485 kW | TBD234V12 | |||||||
| 373-485 kW | CHD234V12CR | |||||||
|
Engine Model Rated Power/kW |
0 | 100 | 200 | 300 | 400 | 500 | 600 | 700 |
Engine Model |
Rated Power |
Fuel Consumption |
Engine Model |
Rated Power |
Fuel Consumption |
||
| TBD234V6 | 186-242 kW | 202-210 g/kW·h | CHD234V6CR | 186-242 kW | 202-210 g/kW·h | ||
| TBD234V8 | 249-323 kW | 198-205 g/kW·h | CHD234V8CR | 252-323 kW | 205-210 g/kW·h | ||
| TBD234V12 | 373-485 kW | 200-207 g/kW·h | CHD234V12CR | 373-485 kW | 200-207 g/kW·h | ||
| ——END—— | |||||||
HND TBD234/CHD234CR DEUTZ-MWM Series Marine Main Engine
This is the list of all series of HND TBD234/CHD234CR DEUTZ-MWM Series Marine Main Engine.
HND DEUTZ-MWM TBD234V6 Marine Main Engine
Engine Model: TBD234V6
Rated Power: 186-242 kW
Fuel Consumption: 202-210 g/kW·h
Speed: 1500-2100 r/min
Emission: TierⅡ/TierⅢ
HND DEUTZ-MWM CHD234V6CR Marine Main Engine
Engine Model: CHD234V6CR
Rated Power: 186-242 kW
Fuel Consumption: 202-210 g/kW·h
Speed: 1500-2100 r/min
Emission: C1/C2
HND DEUTZ-MWM TBD234V8 Marine Main Engine
Engine Model: TBD234V8
Rated Power: 249-323 kW
Fuel Consumption: 198-205 g/kW·h
Speed: 1500-2100 r/min
Emission: TierⅡ/TierⅢ
HND DEUTZ-MWM CHD234V8CR Marine Main Engine
Engine Model: CHD234V8CR
Rated Power: 252-323 kW
Fuel Consumption: 205-210 g/kW·h
Speed: 1500-2100 r/min
Emission: C2
HND DEUTZ-MWM TBD234V12 Marine Main Engine
Engine Model: TBD234V12
Rated Power: 373-485 kW
Fuel Consumption: 200-207 g/kW·h
Speed: 1500-2100 r/min
Emission: TierⅡ/TierⅢ
HND DEUTZ-MWM CHD234V12CR Marine Main Engine
Engine Model: CHD234V12CR
Rated Power: 373-485 kW
Fuel Consumption: 200-207 g/kW·h
Speed: 1500-2100 r/min
Emission: C1/C2
