SDEC S16R2 Marine Auxiliary Engines

The S16R2 series power station products are derived from the military ship platform products of Shanghai and have been further developed based on the products and systems of Mitsubishi Heavy Industries. These products are designed to be the most cost-effective solutions for matching power units ranging from 1600 to 1800 kW.
The S16R2 series engines have been meticulously designed and crafted to meet the high power demands of the generator set support market. Each technical parameter has achieved the current international advanced level, showcasing the series’ commitment to cutting-edge technology.
Described by Shanghai Automotive Industry Corporation (SAIC), this series of engines is characterized by its compact structure, high reliability, excellent fuel efficiency, low noise emissions, and visually appealing design. These features make the engines well-suited for a wide range of applications in the power generation sector.
Manufactured in compliance with industry-leading standards, the S6R2 series engines are the preferred power source for both prime and standby generator sets. This endorsement underscores their reliability and performance as top-tier supporting power solutions for diverse power generation needs.

General Specifications of S16R2 Marine Auxiliary Engines

Engine Type:	16-cylinder
Displacement:	65.37 – 79.9 L
*Bore Stroke:**	170 mm * 220 mm
Advertised Power:	1684 – 1960 kW @ 1500 RPM
Peak Torque:	N/A
Rated Speed:	1500 RPM
Emissision:	N/A
Aspiration :	Turbo Charger/Air-air intercooler
Dry Weight:	6650 – 8200 kg
*Dimension (L W * H):**	3118 mm * 1479 mm * 2030 mm

DuraMac

DCEC ISL8.9 series automotive engine is four-strokes engine with 102 mm bore and 120 mm stroke, Equipped with Bosch (or BYC or Weifu) pump. engine comes with turbocharger and Air- Air intercooler. The prime power range is from 269 HP to 394 HP.

FIND MORE

Fast Gear

The F6A Series Automated Transmission uses the FAST automatic transmission, has six front gears, the transmission ratio step arrangement is reasonable, has very outstanding fuel economy. Adopt hydraulic automatic transmission. The F6A Series Automated Transmission has six gears, each with a different reduction ratio.

FIND MORE

EV Truck

Electric wheel dump trucks use electricity as a power source, completely abandoning traditional fuel engines. This change enables the vehicle to achieve true “zero emissions” during operation, without the emission of pollutants such as carbon monoxide, nitrogen oxides, and particulate matter in the exhaust gas, greatly reducing the pollution to the atmospheric environment.

FIND MORE

DANA Axle

Applying the advanced technology of DANA with high efficiency, fuel economy, strong load torque, low noise,high reliability, lower procurement cost, low repair cost and lower maintenance cost.

FIND MORE

Datong Gear

The Datong HW25712XSJ Heavy Manual No-Sync Gearbox has a torque of 2500 N.m, a gear ratio range of 14.941-1, an oil capacity of 13 L (13.5 L when equipped with a power take-off), an overall length of 993 mm, and a weight of 428 kg.

FIND MORE

Crane Trucks

The DFZ5258JSQSZ6D truck crane is a powerful and versatile vehicle designed for efficient lifting and transportation tasks. Equipped with a YCS06300-61 engine and a Shaanxi Auto Fast gear : 10JS120TA high-low gear with synchronizer、PTO gearbox, it provides strong and stable power for demanding operations.

FIND MORE

SDEC S16R2 Marine Auxiliary Engine Catalogue

Engine Model	Rated Power	Aspiration	Engine Model	Rated Power	Aspiration
S16R2-PTAW-C	1960 kW @ 1500 RPM	TC/Water-air intercooler	S16R2-PTAA2-C	1684 kW @ 1500 RPM	TC/Air-air intercooler

——END——
