HND CHD316 DEUTZ-MWM Marine Main Engine

CHD316 DEUTZ-MWM Series marine main engine represents a propulsion power solution developed by HND based on a mature (DEUTZ) technology platform. It has gained widespread market recognition for its outstanding power performance, exceptional fuel economy, and superior operational reliability. This series is suitable for various types of government vessels, merchant ships, and engineering vessels, capable of meeting propulsion demands across different navigation zones. Equipped with advanced emission control technology, it easily complies with international environmental standards, providing ships with efficient and clean core power assurance.
The product combines robust power, outstanding fuel efficiency, and extended service life. It not only delivers exceptional acceleration performance but also significantly reduces operating costs. Its outstanding structural reliability and full compliance with international environmental standards ensure efficient, economical, and compliant operation of vessels under all navigational conditions.

coming soon…

coming soon…

coming soon…

General Specifications of CHD316 DEUTZ-MWM Series

Bore/Stroke :132/160 mm
Cylinder Arrangement :V type, Angle 60
Cylinder Numbers :
12/16
Unit Cylinder Displacement :
2.19 L
Compression Ratio :15 : 1
Min.No Load Steady Speed(Idle Speed) :600~750 r/min
Ignition Speed(20℃) :150 r/min
Rotation Direction :Anti-clockwise rotation(from flywheel end)
Lube Oil Consumption :≤1.3 g/kW·h



CHD316BV12468-839 kWCHD316BV12
CHD316BV12CR468-839 kWCHD316BV12CR
CHD316BV16624-1107 kWCHD316BV16
CHD316BV16CR624-1107 kWCHD316BV16CR

Engine Model

Rated Power/kW

0200400600800100012001400
HND CHD316 DEUTZ-MWM Series Catalogue

Engine Model

Rated Power

Fuel Consumption

Engine Model

Rated Power

Fuel Consumption

CHD316BV12468-839 kW200-206 g/kW·hCHD316BV12CR468-839 kW200-206 g/kW·h
CHD316BV16624-1107 kW200-206 g/kW·hCHD316BV16CR624-1107 kW200-206 g/kW·h
——END——

HND CHD316 DEUTZ-MWM Series Marine Main Engine

This is the list of all series of HND CHD316 DEUTZ-MWM Series Marine Main Engine.
