CCEC NTA855 Marine Main Engine

CCEC NTA855-M series marine main engine is 6-cylinder inline, 14 liters four-strokes engine with 140 mm (5.5 in) bore and 152 mm (6.0 in) stroke. CCEC NTA855-M series marine main engine equipped with PT Fuel System, comes with turbocharger. The prime power range of CCEC NTA855-M series marine main engine is from 147 HP to 450 HP (110 kW to 336 kW). The torque range of the NTA855-M Series marine main engine is 1044 N.m to 2612 N.m.

CCEC marine main engines have different configurations which have different power output, with code T in the engine model name means turbocharged engine, code TA in the engine model means turbocharge with water-air intercooler and code TAA in the engine model means turbocharge with air-air intercooler. Based on standard CCEC marine main engines, SeaMac provides both heat exchanger cooling and keel cooling marine main engines. SeaMac provides full life cycle services for all our customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.

Coming Soon

General Specifications of NTA855 Series

Engine Type:6 Cylinders, in Line
Displacement:14 L
Bore * Stroke:140 mm * 152 mm
Advertised Power:147 – 450 HP @ 1600 – 2100 RPM
Peak Torque:1044 – 1491 N.m @ 1300 – 1500 RPM
Rated Speed:1600 – 2100 RPM
Emissision:Euro II
Aspiration Method:Turbocharged & Water – Air Intercooler
Dry Weight:1258 – 1303 kg
Dimission Standards:1534 mm * 781 mm * 1355 mm
NT855-M147110 kWNT855-M147
NT855-M200149 kWNT855-M200
NT855–M220164 kWNT855–M220
NT855–M240179 kWNT855–M240
NT855–M250187 kWNT855–M250
NT855–M270201 kWNT855–M270
NT855–M300224 kWNT855–M300
NTA855–M350261 kWNTA855–M350
NTA855–M400A298 kWNTA855–M400A
NTA855–M400B298 kWNTA855–M400B
NTA855–M450336 kWNTA855–M450

Engine Model

Rated Power/kW

050100150200250300350
CCEC NTA855 Marine Main Engine Catalogue

Engine Model

Rated Power

Aspiration

Engine Model

Rated Power

Aspiration

NT855 – M147147 HP @ 1600 RPMTurbochargedNT855 – M200200 HP @ 1800 RPMTurbocharged
NT855 – M220220 HP @ 1800 RPM
TurbochargedNT855 – M240240 HP @ 1800 RPMTurbocharged
NT855 – M250250 HP @ 1800 RPMTurbochargedNT855 – M270270 HP @ 1800 RPM
Turbocharged
NT855 – M300300 HP @ 1800 RPMTurbochargedNTA855 – M350350 HP @ 1800 RPMWater – Air Intercooler
NTA855 – M400A400 HP @ 1800 RPMWater – Air IntercoolerNTA855 – M400B400 HP @ 2100 RPMWater – Air Intercooler
NTA855 – M450450 HP @ 1800 RPMWater – Air Intercooler
——END——

CCEC NTA855 Series Marine Main Engine

This list including all models of CCEC NTA855 Series Marine Main Engine.
Click here to find marine engines by type (Fuel System & Power Range).

CCEC NT855-M147 Marine Engine

CCEC NT855-M147 Marine Engine

Power: 110 kW (147 HP) @ 1600 RPM
Rating Type: Continuous
Fuel System: PT
Aspiration: Turbocharged
Emission Standard: N/A

CCEC NTA855 – M350 Marine Engine

CCEC NTA855 – M350 Marine Engine

Power: 261 kW (350 HP) @ 1800 RPM
Rating Type: Continuous
Fuel System: PT
Aspiration: TC & Water – Air Intercooler
Emission Standard: N/A

CCEC NTA855 – M400A Marine Engine

CCEC NTA855 – M400A Marine Engine

Power: 298 kW (400 HP) @ 1800 RPM
Rating Type: Continuous
Fuel System: PT
Aspiration: TC & Water – Air Intercooler
Emission Standard: N/A

CCEC NTA855 – M400B Marine Engine

CCEC NTA855 – M400B Marine Engine

Power: 298 kW (400 HP) @ 2100 RPM
Rating Type: Continuous
Fuel System: PT
Aspiration: TC & Water – Air Intercooler
Emission Standard: N/A

CCEC NTA855 – M450 Marine Engine

CCEC NTA855 – M450 Marine Engine

Power: 336 kW (450 HP) @ 1800 RPM
Rating Type: Continuous
Fuel System: PT
Aspiration: TC & Water – Air Intercooler
Emission Standard: N/A
